Introduction to the mtarm Package

Multivariate Threshold Autoregressive (TAR) models

The mtarm package provides a computational tool designed for Bayesian estimation, inference, and forecasting in multivariate Threshold Autoregressive (TAR) models. These models provide a versatile approach for modeling nonlinear multivariate time series and include multivariate Self-Exciting Threshold Autoregressive (SETAR) and Vector Autoregressive (VAR) models as particular cases (Vanegas, Calderón V, and Rondón 2025). The package accommodates a broad class of innovation distributions beyond the Gaussian assumption, such as Student- $t$ , slash, symmetric hyperbolic, Laplace, contaminated normal, skew-normal, and skew- $t$ distributions, thereby enabling robust modeling of heavy tails, asymmetry, and other non-Gaussian characteristics.

Installation

Install from GitHub

remotes::install_github("lhvanegasp/mtarm")

Install from CRAN

install.packages("mtarm")

Application: Temperature, precipitation, and two river flows in Iceland

Dataset

The data are available in the object `iceland.rf` and were obtained from (Tong 1990), who provided a detailed description of the geographical and meteorological characteristics of the rivers and analyzed each series individually. Subsequently, (Tsay 1998) conducted a bivariate analysis of the same dataset. The focus is on the bivariate time series $\{(Y_{1,t},Y_{2,t})^{\top}\}_{t\geq 1}$ , where $Y_{1,t}$ and $Y_{2,t}$ denote the daily river flow (in cubic meters per second, ${m}^3/{s}$ ) of the Jökulsá Eystri and Vatnsdalsá rivers, respectively. The sample covers the period from 1972 to 1974, comprising 1095 observations. The exogenous variables include daily precipitation $X_t$ , measured in millimeters ( ${mm}$ ), and temperature $Z_t$ , measured in degrees Celsius ( $^\circ\mathrm{C}$ ), both recorded at the meteorological station in Hveravellir. Precipitation corresponds to the accumulated rainfall from 9:00 A.M. of the previous day to 9:00 A.M. of the current day.

library(mtarm)
data(iceland.rf)
str(iceland.rf)
#> 'data.frame':    1096 obs. of  5 variables:
#>  $ Vatnsdalsa   : num  16.1 19.2 14.5 11 13.6 12.5 10.5 10.1 9.68 9.02 ...
#>  $ Jokulsa      : num  30.2 29 28.4 27.8 27.8 27.8 27.8 27.8 27.8 27.3 ...
#>  $ Precipitation: num  8.1 4.4 7 0 0 0 1.9 1.2 0 0.1 ...
#>  $ Temperature  : num  0.9 1.6 0.1 0.6 2 0.8 1.4 1.3 2.2 0.1 ...
#>  $ Date         : Date, format: "1972-01-01" "1972-01-02" ...

summary(iceland.rf[,-5])
#>    Vatnsdalsa        Jokulsa       Precipitation     Temperature
#>  Min.   : 3.670   Min.   : 22.00   Min.   : 0.000   Min.   :-22.4000
#>  1st Qu.: 6.100   1st Qu.: 26.70   1st Qu.: 0.000   1st Qu.: -4.2000
#>  Median : 7.500   Median : 31.40   Median : 0.300   Median :  0.3000
#>  Mean   : 8.938   Mean   : 41.15   Mean   : 2.519   Mean   : -0.4407
#>  3rd Qu.: 9.240   3rd Qu.: 50.90   3rd Qu.: 2.500   3rd Qu.:  3.9000
#>  Max.   :54.000   Max.   :143.00   Max.   :79.300   Max.   : 13.9000

plot(ts(as.matrix(iceland.rf[,-5])), main="Iceland")

Model specification

Following (Tsay 1998), the series are modeled using a $\mathrm{TAR}(2; p=(15,15), q=(4,4), d=(2,2))$ specification given by

$$Y_t=\sum\limits_{j=1}^2 I(Z_{t-h}\in(c_{j-1},c_j])\Big(\!{\phi}_0^{^{(j)}}+\sum\limits_{i=1}^{15}\boldsymbol{\phi}_i^{^{(j)}}Y_{t-i}+\sum\limits_{i=1}^{4}\boldsymbol{\beta}_i^{^{(j)}}\!X_{t-i}+\sum\limits_{i=1}^{2}{\delta}_i^{^{(j)}}\!Z_{t-i}+\epsilon_t^{^{(j)}}\!\Big),$$

where $\epsilon_t^{^{(j)}}$ is the error term. The last 55 observations (from November 7 to December 31, 1974), corresponding to $5\%$ of the sample, are excluded from the estimation stage and reserved for out-of-sample forecast evaluation. The following code requests the estimation for the $\mathrm{TAR}(2; p=(15,15), q=(4,4), d=(2,2))$ specification under Gaussian, Slash, Student- $t$ , and Laplace error distributions.

Parameter estimation

fits <- mtar_grid(~ Jokulsa + Vatnsdalsa | Temperature | Precipitation,
                  data=iceland.rf, subset={Date<="1974-11-06"},
                  row.names=Date, nregim.min=2, nregim.max=2, p.min=15,
                  p.max=15, q.min=4, q.max=4, d.min=2, d.max=2,
                  n.burnin=200, n.sim=300, n.thin=3, ssvs=TRUE,
                  dist=c("Gaussian","Slash","Student-t","Laplace"),
                  plan_strategy="multisession")

fits
#>
#>
#> Sample size          :1026 time points (1972-01-16 to 1974-11-06)
#>
#> Output Series        :Jokulsa    |    Vatnsdalsa
#>
#> Threshold Series (TS):Temperature with a estimated delay equal to 0
#>
#> Exogenous Series (ES):Precipitation
#>
#> Error Distribution   :Gaussian
#>
#> Number of regimes    :2 to 2
#>
#> Deterministics       :Intercept
#>
#> Autoregressive orders:15 to 15
#>
#> Maximum lags for ES  :4 to 4
#>
#> Maximum lags for TS  :2 to 2

Model comparison using forecast accuracy measures

Adjusted within-sample

The following code requests Deviance Information Criterion (DIC) (Spiegelhalter et al. 2002, 2014) and Watanabe-Akaike Information Criterion (WAIC) (Watanabe 2010) values.

DICs <- DIC(fits)
DICs
#>                         DIC
#> Gaussian.2.15.4.2  9436.697
#> Laplace.2.15.4.2   8004.425
#> Slash.2.15.4.2     8937.387
#> Student-t.2.15.4.2 7568.318

WAICs <- WAIC(fits)
WAICs
#>                         WAIC
#> Gaussian.2.15.4.2   9548.505
#> Laplace.2.15.4.2    8128.171
#> Slash.2.15.4.2     11455.987
#> Student-t.2.15.4.2  7611.521

Out-of-sample

In addition, the following code provides the median of the log-score (Good 1952), the Energy Score (ES) (Gneiting et al. 2008)—a multivariate extension of the Continuous Ranked Probability Score (CRPS)(Matheson and Winkler 1976; Grimit et al. 2006)—and the Absolute Percentage Error (APE), all computed from the observed and forecasted values for the last 55 observations.

newdata <- subset(iceland.rf, Date>"1974-11-06")
oos <- out_of_sample(fits, newdata=newdata, n.ahead=nrow(newdata),
                     by.component=TRUE, FUN=median)
oos[,c(1,2,5,6)]
#>                    Log.Score Energy.Score  Jokulsa.APE Vatnsdalsa.APE
#> Gaussian.2.15.4.2   3.024220 1.646199e+00 4.619251e+00   1.991865e+01
#> Laplace.2.15.4.2    3.314595 1.935466e+00 4.052850e+00   1.854437e+01
#> Slash.2.15.4.2     10.536189 5.020090e+12 1.126195e+13   1.797553e+14
#> Student-t.2.15.4.2  3.613492 2.466212e+00 3.573211e+00   2.159836e+01

Residuals

res <- residuals(fits$`Student-t.2.15.4.2`)

par(mfrow=c(1,2))
qqnorm(res$full, pch=20, col="blue", main="")
abline(0, 1, lty=3)
hist(res$full, freq=FALSE, xlab="Quantile-type residual", ylab="Density", main="")
curve(dnorm(x), col="blue", add=TRUE)

par(mfrow=c(1,2))
acf(res$full, col="blue", main="")
pacf(res$full, col="blue", main="")

Forecasting

pred <- predict(fits$`Student-t.2.15.4.2`, newdata=newdata, n.ahead=nrow(newdata),
                row.names=Date, credible=0.8)

head(pred$summary)
#>            Jokulsa.Mean Jokulsa.Lower Jokulsa.Upper Vatnsdalsa.Mean
#> 1974-11-07     27.21316      25.76946      28.46264        7.404870
#> 1974-11-08     27.01323      24.86831      28.75462        7.472812
#> 1974-11-09     26.75234      24.75151      29.56973        7.373822
#> 1974-11-10     26.58236      24.13360      29.37635        7.240455
#> 1974-11-11     26.44036      23.55372      29.06317        7.107537
#> 1974-11-12     26.41050      23.08747      28.86329        6.908370
#>            Vatnsdalsa.Lower Vatnsdalsa.Upper
#> 1974-11-07         6.835809         8.288433
#> 1974-11-08         6.311423         8.693522
#> 1974-11-09         5.664342         8.886327
#> 1974-11-10         5.037076         8.682407
#> 1974-11-11         4.839237         9.409943
#> 1974-11-12         4.539432         9.455680
tail(pred$summary)
#>            Jokulsa.Mean Jokulsa.Lower Jokulsa.Upper Vatnsdalsa.Mean
#> 1974-12-26     25.84591      22.73476      29.33715        6.308694
#> 1974-12-27     25.79648      22.01993      28.75240        6.239637
#> 1974-12-28     25.82312      22.80695      29.42083        6.262354
#> 1974-12-29     25.84683      22.47483      29.06715        6.344775
#> 1974-12-30     25.80999      23.10747      29.04295        6.316401
#> 1974-12-31     25.87735      23.28161      29.61837        6.268220
#>            Vatnsdalsa.Lower Vatnsdalsa.Upper
#> 1974-12-26         2.423741         8.819013
#> 1974-12-27         2.673335         9.103902
#> 1974-12-28         3.046894         9.275374
#> 1974-12-29         2.791733         8.786324
#> 1974-12-30         3.086214         8.922990
#> 1974-12-31         2.948773         9.080198

Convergence diagnostics

Geweke statistic

geweke_diagTAR(fits$`Student-t.2.15.4.2`)
#>
#> Fraction in 1st window = 0.1
#>
#> Fraction in 2nd window = 0.5
#> Thresholds:
#>
#> threshold 0.12569
#>
#>
#> Autoregressive coefficients:
#>                                Regime 1   Regime 2
#> Jokulsa:(Intercept)           -2.153633  0.7509429
#> Jokulsa:Jokulsa.lag( 1)        1.438730  0.5940345
#> Jokulsa:Jokulsa.lag( 2)       -0.322513 -0.8607335
#> Jokulsa:Vatnsdalsa.lag( 1)     1.809104 -0.6580059
#> Jokulsa:Vatnsdalsa.lag( 2)    -2.248465  0.3091728
#> Jokulsa:Temperature.lag(1)               1.2735817
#> Jokulsa:Temperature.lag(2)              -0.0335677
#> Vatnsdalsa:(Intercept)        -2.175712  0.1368150
#> Vatnsdalsa:Jokulsa.lag( 1)     1.239638 -0.6052781
#> Vatnsdalsa:Jokulsa.lag( 2)    -0.709139  0.3380195
#> Vatnsdalsa:Vatnsdalsa.lag( 1)  0.572919  0.8321379
#> Vatnsdalsa:Vatnsdalsa.lag( 2) -0.046631 -0.8718642
#> Vatnsdalsa:Temperature.lag(1)           -0.5399509
#> Vatnsdalsa:Temperature.lag(2)           -0.0027549
#>
#>
#> Scale parameter:
#>                       Regime 1 Regime 2
#> Jokulsa.Jokulsa         2.9745 1.941601
#> Jokulsa.Vatnsdalsa      3.0663 0.087331
#> Vatnsdalsa.Vatnsdalsa   1.9048 0.931698
#>
#>
#> Extra parameter:
#>
#> nu -0.2317

Effective sample size

effectiveSize_TAR(fits$`Student-t.2.15.4.2`)
#> Thresholds:
#>
#> threshold 68.963
#>
#>
#> Autoregressive coefficients:
#>                               Regime 1 Regime 2
#> Jokulsa:(Intercept)             196.21  231.123
#> Jokulsa:Jokulsa.lag( 1)         300.00  124.447
#> Jokulsa:Jokulsa.lag( 2)         300.00   97.811
#> Jokulsa:Vatnsdalsa.lag( 1)      230.46  207.389
#> Jokulsa:Vatnsdalsa.lag( 2)      229.69  300.000
#> Jokulsa:Temperature.lag(1)              249.284
#> Jokulsa:Temperature.lag(2)              432.022
#> Vatnsdalsa:(Intercept)          230.77   90.951
#> Vatnsdalsa:Jokulsa.lag( 1)      300.00  248.125
#> Vatnsdalsa:Jokulsa.lag( 2)      253.19  300.000
#> Vatnsdalsa:Vatnsdalsa.lag( 1)   144.64   41.228
#> Vatnsdalsa:Vatnsdalsa.lag( 2)   179.61   44.125
#> Vatnsdalsa:Temperature.lag(1)           397.460
#> Vatnsdalsa:Temperature.lag(2)           300.000
#>
#>
#> Scale parameter:
#>                       Regime 1 Regime 2
#> Jokulsa.Jokulsa         66.831   303.01
#> Jokulsa.Vatnsdalsa     223.418   251.58
#> Vatnsdalsa.Vatnsdalsa  149.255   167.11
#>
#>
#> Extra parameter:
#>
#> nu 336.76

Gneiting, Tilmann, Laura I. Stanberry, Eric P. Grimit, Leonhard Held, and Nicholas A. Johnson. 2008. “Assessing Probabilistic Forecasts of Multivariate Quantities, with an Application to Ensemble Predictions of Surface Winds.” TEST 17 (2): 211–35. https://doi.org/10.1007/s11749-008-0114-x.

Good, I. J. 1952. “Rational Decisions.” Journal of the Royal Statistical Society: Series B (Methodological) 14 (1): 107–14.

Grimit, Eric P., Tilmann Gneiting, Veronica J. Berrocal, and Nicholas A. Johnson. 2006. “The Continuous Ranked Probability Score for Circular Variables and Its Application to Mesoscale Forecast Ensemble Verification.” Quarterly Journal of the Royal Meteorological Society 132 (621C): 2925–42. https://doi.org/10.1256/qj.05.235.

Matheson, James E., and Robert L. Winkler. 1976. “Scoring Rules for Continuous Probability Distributions.” Management Science 22 (10): 1087–96. https://doi.org/10.1287/mnsc.22.10.1087.

Spiegelhalter, D. J., N. G. Best, B. P. Carlin, and A. Van Der Linde. 2014. “The Deviance Information Criterion: 12 Years on.” Journal of the Royal Statistical Society Series B: (Statistical Methodology) 76 (3): 485–93.

Spiegelhalter, D. J., N. G Best, B. P. Carlin, and A. Van Der Linde. 2002. “Bayesian Measures of Model Complexity and Fit.” Journal of the Royal Statistical Society: Series B (Statistical Methodology) 64 (4): 583–639.

Tong, Howell. 1990. Non‑linear Time Series: A Dynamical System Approach. Oxford Statistical Science Series. Oxford, UK: Oxford University Press.

Tsay, Ruey S. 1998. “Testing and Modeling Multivariate Threshold Models.” Journal of the American Statistical Association 93 (443): 1188–1202. https://doi.org/10.1080/01621459.1998.10473779.

Vanegas, L. H., S. A. Calderón V, and L. M. Rondón. 2025. “Bayesian Estimation of a Multivariate TAR Model When the Noise Process Distribution Belongs to the Class of Gaussian Variance Mixtures.” International Journal of Forecasting. https://doi.org/https://doi.org/10.1016/j.ijforecast.2025.08.001.

Watanabe, S. 2010. “Asymptotic Equivalence of Bayes Cross Validation and Widely Applicable Information Criterion in Singular Learning Theory.” The Journal of Machine Learning Research 11: 3571–94.

Luis Hernando Vanegas

Sergio Alejandro Calderón

Luz Marina Rondón
